hello@metartmesh.comMETART-WW06-31024-decorative-privacy-wire-mesh
Material: Stainless Steel Wire Strips Grade 201, 304, or 316.
Type: Rigid Decorative Wire Mesh
Opening Area: 20%
Estimated Square Meter Weight: Approx 8.4kg/㎡
Finish: Mill Finish
Screen Width: Custom made.
Screen Length: Custom made.
Both the METART-WW05 and METART-WW06 series are quite comparable to one another. Both of them are constructed with flat wire strips. The main distinction between the two series is that the wire strips of the WW06 series have grooves on their surface, whereas the surface of the wire strips of the WW05 series is smooth. #31024 indicates that the wire is approximately 3 millimetres wide (2.9 millimetres wide) and 1 millimetre thick, and the aperture is around 2.4 millimetres.
This design also has a very high level of privacy and utilises a material that is perfect for use in privacy screens, in particular screen panels such as those used for swimming pool fence panels.
Specification Table.
Material |
Stainless Steel Wire Strips Grade 201,304 or 316. |
Type |
Rigid Decorative Wire Mesh |
Flat Wire Strip(WidthxThickness): |
2.9x1mm |
Clear Hole Size |
2.4mm |
Overall thickness of the fabric |
2.2mm |
Opening Area |
20% |
Privacy Rate |
80% |
Estimated Square Meter Weight |
8.4kg/㎡ |
Finish |
Stainless Steel Mill Finish |
The way of cutting |
Straight Cut |
All optional ways of cut |
Straight Cut, Diamond Cut |
All optional Finishes |
Mill Finish ( Original stainless steel bright finish), |
Custom made specifications and Mini order accepted. |
|
Note: All the measurements including wire thickness, diameter, opening, and overall thickness are nominal numbers. The actual specification might have a tiny bit of tolerance according to fabrication |
