METART-WW12-Balustrade Infill Architectural Wire Mesh

Specification

Material: Stainless Steel 201, 304, and marine grade ss316

Type: Rigid Architectural Mesh

Opening Area: 59%

Estimated Square Meter Weight: Approx 8kg/㎡

Finish: Mill Finish

Screen Width: Custom made.

Screen Length: Custom made.

GET A QUOTE

Introduction

With the same 2.75mm wire diameter as WW11, METART WW12 is a double-reinforced variant of WW10 and WW11. The hole size was changed from 15.4mm to 9mm. The mesh construction would be more robust with a smaller aperture. This design is appropriate for building mesh façades, balustrade mesh panels, security fence panels, divider screen infill wire mesh, etc.
Specification Table.

Material

Stainless Steel 304 or 316, optional

Type

Rigid Architectural Wire Mesh

Wire Diameter

2.75mm

Clear Hole Size

9mm

Overall thickness of the fabric

3.3mm

Opening Area

59%

Privacy Rate

41%

Estimated Square Meter Weight

8kg/㎡

Finish

Stainless Steel Mill Finish

The way of cutting

Straight Cut

All optional ways of cut

Straight Cut, Diamond Cut

All optional Finish

Mill Finish ( Original stainless steel bright finish),
Antique Bronze plating, Antique Copper plating, Antique brass plate, PVD vacuum titanium plated, Painted, PVDF Coated,

Custom made specifications and Mini order accepted.

Note:

All the measurements including wire thickness, diameter, opening, and overall thickness are nominal numbers. The actual specification might have a tiny bit of tolerance according to fabrication
