Rimmed Wire Mesh Filter Discs
Material of Mesh: Stainless Steel, Brass/copper/bronze & special alloy
Material of the rim: Aluminum or Stainless Steel
Type: Industrial Screen Filter Discs.
Pattern of Weave: Plain & Twill Weave, Duch Weave, Crimped Mesh pattern.
Mesh Count: Customized.
Wire Diameter: Customized.
OD: Customized.
Rimmed Wire Mesh Filter Discs are also known as framed filter mesh disc screens which are basically made of wire mesh and wire cloth fabrics with a metal frame. Based on customers' requirements, the frame is generally made of either aluminum or stainless steel.
The rimming procedure was completed by roll-forming workmanship.
As a wire mesh manufacturer and stockist, METART has a great variety of mesh counts and wire gauge ranges, from the crimped coarse wire mesh to the super fine filter wire cloth.
The infill wire mesh can be a single laser wire mesh or sandwich-like multi-layer wire screens. Normally, one or more layers of fine wire cloth will be placed in the middle of the discs and the stronger wire mesh will be put on the outsides of the disc protective layers during filtration.
After being rimmed, the surfaces of the wire mesh filter discs become flatter and tighter. And the impact resistance has increased.
Material of the infill wire screen discs.
-Stainless Steel 304 or 304L Wire Mesh and Wire Cloth
-Stainless Steel 316 or 316L Wire Mesh and Wire Cloth
-Stainless Steel 201 Wire Mesh
-Stainless Steel 310 wire mesh
-Stainless Steel 321 wire mesh
-Copper Wire Mesh, Brass Wire Mesh, or Phosphor Bronze Wire Mesh
-Carbon Steel Wire Mesh and Wire Mesh Cloth.
-Exotic Alloy Wire Mesh and Wire Cloth including Inconel wire mesh, Incoloy Wire Mesh, Nichrome Wire Mesh, Duplex Stainless Steel Mesh, Super Duplex Stainless Steel wire mesh, 940L Wire cloth, Nickel Wire cloth, Monel Wire Cloth, Hastelloy wire screens, etc.
Features of Rimmed Fitler Screen Discs.
-Flatter and tighter surface
-Smoother edges
-Longer using life
-Easy to install
-Filter Screens for polymer filtration
-Screens for the plastic extrusion industry.
-Food and beverage processing industry.
-Vegetable oil processing.
-Coffee filter or tea filter screens.
