hello@metartmesh.comArchitectural Stainless Steel Mesh-METART-WW17HW
Material: Stainless Steel Grade 201,304,316
Type: Rigid Decorative Wire Mesh
Opening Area: 30%
Estimated Square Meter Weight: Approx 6.9kg/㎡
Finish: Mill Finish
Screen Width: Custom made.
Screen Length: Custom made.
The Heavy-Weighted variation of pattern #WW17 is the architectural mesh pattern METART WW17HW.
Among the WW17 series, it is the most widely used. It is made of vertically 1.8mm pre-waved round wires and horizontally 2.4x1.2mm grooved stainless steel strips. It receives more waves than WW17MW because the wave wires' angles are smaller. The waves also appear more obvious. Weft wire density at this point is higher than WW17MW, giving the screen more crimps and strength.
When left unfinished, the entire surface has the lovely, shiny appearance of a still lake that has been ruffled by the wind.
Since it is the most robust one in this pattern, it can be used for both commercial and residential construction projects. Additionally, some environments require comparatively higher security, and it is preferred to be an exterior decoration material.
Specification Table.
Material |
Stainless Steel Grade 201,304 or 316. |
Type |
Rigid Decorative Wire Mesh |
Round Wire Diameter (Single wire) |
1.8mm |
Flat Wire Strip(width x thickness): |
2.4x1.2mm |
Flat Wire Strip Pitch |
6.4mm |
Round Wire Hole Pitch |
11m |
The total thickness of the fabric |
4.6mm |
Opening Area |
30% |
Privacy Rate |
70% |
Weight |
6.9kg/Square Meter |
Finish |
Antique Copper Plated |
The way of cutting |
Straight Cut |
All optional ways of cut |
Straight Cut Only |
All optional Finish |
Mill Finish ( Original stainless steel bright finish), |
Custom made specifications and Mini order accepted. |
|
Note: All the measurements including wire thickness, diameter, opening, and overall thickness are nominal numbers. The actual specification might have a tiny bit of tolerance according to fabrication |
