METART-WW06-31032-Wine Bar Decorative Wire Mesh

Specification

Material: Stainless Steel Wire Strips Grade 201,304, or marine grade 316.

Type: Rigid Decorative Wire Mesh

Opening Area: 27.5%

Estimated Square Meter Weight: Approx 7.2kg/㎡

Finish: Mill Finish

Screen Width: Custom made

Screen Length: Custom made.

GET A QUOTE

Introduction

The physical characteristics of METART-WW06-31032 are exactly the same as those of WW06-31024.

There are several areas in which the two are comparable to one another. On the other hand, the diameter of the hole has been somewhat enlarged. It gives the mesh an opening rate that is significantly higher than that of the other available choices. Wires measuring 2.9 millimetres in width and 1 millimetre in thickness are used to create this mesh structure. The diameter of the clear void is 3.2 millimetres on each side. There is no additional finish that is referred to be mill finished on the sample. You have the option of picking other colours in addition to those that are presented if this meets your requirements in a more satisfactory manner. Some of the applications that are suitable for use with this material include cabinet door mesh, privacy screens, partition screen mesh, wall cladding mesh, railing system infill mesh, and swimming pool fence panels.

Specification Table.

Material

Stainless Steel Grade 201,304 or 316.

Type

Rigid Decorative Wire Mesh

Flat Wire Strip(WidthxThickness):

3x1.0mm

Clear Hole Size

3.2mm

Overall thickness of the fabric

2.2mm

Opening Area

27.5%

Privacy Rate

72.5%

Estimated Square Meter Weight

7.2kg/㎡

Finish

Stainless Steel Mill Finish

The way of cutting

Straight Cut

All optional ways of cut

Straight Cut, Diamond Cut

All optional Finishes

Mill Finish ( Original stainless steel bright finish),
Antique Bronze plating, Antique Copper plating, Antique brass plate, Vacuum titanium plated, Painted, PVDF Coated,

Custom made specifications and Mini order accepted.

Note:

All the measurements including wire thickness, diameter, opening, and overall thickness are nominal numbers. The actual specification might have a tiny bit of tolerance according to fabrication
