hello@metartmesh.comMETART-WW06-31053-Architectural Divider Infill Wire Mesh
Material: Stainless Steel Grade 201,304 or 316.
Type: Rigid Architectural Wire Mesh
Opening Area: 41%
Square Meter Weight: Approx 5.1kg/㎡
Finish: Mill Finish
Screen Width: Custom made
Screen Length: Custom made
Among the WW06 series, METART-WW06-31053 is the most widely used design. A 2.9mm wide wire strip, 1mm wire thickness, and about 5.3mm aperture size are represented by the #31053 code. The milling process ends with a diamond-cut sample like this. You may make it in whatever shade you choose! This mesh design may be used for a variety of decorative purposes, including interior wall cladding, commercial wall cladding, cabinet metal grille inserts, and more. Balustrade infill mesh panels and interior ornamental screens are two other applications.
Specifications Table.
Material |
Stainless Steel Grade 201, 304 or 316. |
Type |
Rigid Architectural Mesh |
Flat Wire Strip(widthxthickness): |
3x1.0mm |
Clear Hole Size |
5.3mm |
The total thickness of the fabric |
2mm |
Opening Area |
41% |
Block out |
59% |
Privacy Rate |
59% |
Estimated Square Meter Weight |
5.1kg/㎡ |
Finish |
Stainless Steel Mill Finish |
The way of cutting |
Diamond Cut |
All optional ways of cut |
Straight Cut, Diamond Cut |
All optional Finishes |
Mill Finish ( Original stainless steel bright finish), |
Custom made specifications and Mini order accepted. |
|
Note: All the measurements including wire thickness, diameter, opening, and overall thickness are nominal numbers. The actual specification might have a tiny bit of tolerance according to fabrication |
