METART-WW26B-Interior Partition Decorative Metal Mesh

Specification

Raw Material: Stainless Steel Grade 201, 304 and marine grade 316

Mesh Type: Rigid Mesh

Opening Area: 46%

Estimated Square Meter Weight: Approx 6kg/㎡

Finish: Mill Finish

Sheet Size: Custom made.

GET A QUOTE

Introduction

This is the opposite side of our decorative wire mesh pattern METART-26, which is named WW26B.
Fore the details specification, please refer to the following table.

Raw Material	SS201, 304,316, aluminium and other alloys.
Mesh Type	Rigid Architectural Mesh
Wire Strip (width x thickness)	2.2x1.2mm
Wire Rod Diameter	1.5mm
Clear Hole Size	2x16mm
Strip Pitch	4mm
Rod Pitch	17.5mm
Overall thickness of the fabric	3.1mm
Opening rate	46%
Privacy Rate	54%
Estimated Square Meter Weight	6kg/㎡
Finish	Mill Finish.
The way of cutting	Straight Cut
All optional ways of cut	Straight Cut Only
All optional Finishes	Mill Finish ( Original stainless steel bright finish）, Antique Bronze plating, Antique Copper plating, Antique brass plate, vacuum titanium plated, Painted, PVDF Coated,
Customized specifications and Mini order accepted.
Note: All the measurements including wire thickness, diameter, opening, and overall thickness are nominal numbers. The actual specification might have a tiny bit of tolerance according to fabrication
