hello@metartmesh.comMETART-WW14-Stainless Steel Designer Wire Mesh
Material: Stainless Steel Grade 201,304 or marine grade 316
Type: Rigid Decorative Wire Mesh
Opening Area: 28%
Estimated Square Meter Weight: Approx 8.6kg/㎡
Finish: Mill Finish
Screen Width: Custom made.
Screen Length: Custom made.
The wire in METART WW14 is substantially wider than the wire in pattern WW13.
This stainless steel woven wire mesh is appropriate for wall cladding, interior and external decorating, and store fitting.
To give it a fashionable appearance, you may either utilize it mill finished or have copper, brass, or titanium plated onto it in certain colors.
Specification Table.
Material |
Stainless Steel Grade 201, 304, or 316. |
Type |
Rigid Architectural Wire Mesh |
Flat Wire Strip (Widhtxthickness): |
3.x1.2mm |
Clear Hole Size |
3.4mm |
Overall thickness of the fabric |
2mm |
Opening Area |
28% |
Privacy Rate |
72% |
Estimated Square Meter Weight |
8.6kg/㎡ |
Finish |
Stainless Steel Mill Finish |
The way of cutting |
Straight Cut |
All optional ways of cut |
Straight Cut, Diamond Cut |
All optional Finish |
Mill Finish ( Original stainless steel bright finish), |
Customized specifications and Mini order accepted. |
|
Note: All the measurements including wire thickness, diameter, opening, and overall thickness are nominal numbers. The actual specification might have a tiny bit of tolerance according to fabrication |
