hello@metartmesh.comMETART-WW24-Architectural Stainless Steel Railing Infill Wire Mesh
Raw Material: Stainless Steel 201,304,316
Mesh Type: Rigid Architectural Wire Mesh
Opening Rate: 48%
Estimated Square Meter Weight: Approx 8.1kg/㎡
Finish: Mill Finish
Sheet Width: Custom made.
Sheet Length: Custom made.
Pattern METART WW24 is a heavy-duty architectural woven wire mesh that is made of stainless steel wires, including grade 201, 304 and marine grade 316 based on customers' requirements.
The flat wire is made of 3.8mm wide and 1.5mm thick stainless steel wire strips and the regular round wires are made of 2mm wire gauge.
With an approx 5x6mm slot hole size, it has superb structural strength.
This ornamental woven wire mesh is suitable for both indoor and outdoor ornamental projects including stainless steel railing systems infill panels, airport architectural fencing panels, facade shading architectural mesh screens, etc.
Specifications Table.
Raw Material |
Stainless Steel 201,304 or 316 |
Mesh Type |
Rigid Architectural Wire Mesh |
Wire Strips(Widthxthickness) |
3.8x1.5mm |
Wire Rod Diameter |
2mm |
Clear Hole Size |
5x6.2mm |
Strip Pitch |
10mm |
Rod Pitch |
6.5mm |
Overall thickness of the fabric |
3.5mm |
Opening rate |
48% |
Privacy Rate |
52% |
Estimated Square Meter Weight |
8.1kg/㎡ |
Finish |
Stainless Steel Mill Finish |
The way of cutting |
Straight Cut |
All optional ways of cut |
Straight Cut Only |
All optional Finish |
Mill Finish ( Original stainless steel bright finish), |
Custom made specifications and Mini order accepted. |
|
Note: All the measurements including wire thickness, diameter, opening, and overall thickness are nominal numbers. The actual specification might have a tiny bit of tolerance according to fabrication |
